Castle Talon 15, 15V 15AMP ESC with Heavy Duty BEC

Artikelnr: CC-010-0129-00

We packed as much brute power and intelligence into this tiny layout as we possibly could and came up with a 15 amp* controller with ability to sustain an 8 amp BEC! Talon 15 measures just 1.1” long and is under 0.6” wide! At nearly the size of a quarter, this ESC supports an outlandish 8 amp** peak BEC with output voltage of 5.5 VDC. Applications range from foamies to micro and sub-micro helis running up to 4S and pulling 15 amps. As with any Castle ESC, the Talon 15 offers Castle’s industry-leading functions, not to mention easy programming using the Castle Link USB adapter (coupon for free Castle Link included), or the Castle Field Link Portable Programmer (sold separately).

49,90
Voorraad
Voorraad:
  0  items
Beschrijving

CC-010-0129-00

Extra informatie
Retail price $33.99
Item number 010-0129-00
Input voltage MIN: 2S LiPo
MAX: 4S LiPo
Max continuous amperage at full throttle 15 amps*
BEC voltage (voltage regulator for powering radio and servos) 5.5 volts
BEC output 8 amp peak**
3 amp continuous
(always check servo draw prior to first flight)
Dimensions

Width: 0.58" (14.7mm)
Length: 1.10" (27.9mm)
Depth: 0.32" (8.1mm)

Weight (with wires) 0.25 oz. (7.2g)
Weight (without wires) 0.12 oz (3.4g)
Items needed for operation or installation

Battery connector and motor connectors sold separately

Programmability Fully programmable Castle feature set using Castle Link USB adapter (coupon for free Castle Link adapter included in package) and freely downloadable Castle Link Windows software.
